Key Selection Information
| Selection Parameter | Confirmed Information |
|---|---|
| Package | SOIC-14 |
| Output Current | 20mA |
| Number of Channels | 4 |
| Operating Temperature | 0℃~+70℃ |
| Vos – Input Offset Voltage | 3mV |
| Slew Rate | 500V/ms |
| Input Offset Current(Ios) | 2nA |
Product Overview
LM324DR is a Texas Instruments operational amplifier identified by the exact orderable code LM324DR. Its confirmed technical identity includes Output Current 20mA, Number of Channels 4, Operating Temperature 0℃~+70℃, Vos – Input Offset Voltage 3mV.
The exact device is described as: 20mA 4 3mV 500V/ms 80dB 20nA 700uA 1.2MHz SOIC-14 Instrumentation, Op Amps, Buffer Amps. Selection should be based on the exact package and the operating conditions required by the design, rather than on a nearby family member or a generic part number.
Technical Specifications
| Parameter | Value |
|---|---|
| Package | SOIC-14 |
| Output Current | 20mA |
| Number of Channels | 4 |
| Operating Temperature | 0℃~+70℃ |
| Vos – Input Offset Voltage | 3mV |
| Slew Rate | 500V/ms |
| Input Offset Current(Ios) | 2nA |
| Common Mode Rejection Ratio(CMRR) | 80dB |
| Ib – Input Bias Current | 20nA |
| Input Offset Voltage Drift(Vos TC) | 7uV/℃ |
| Quiescent Current | 700uA |
| Gain Bandwidth Product | 1.2MHz |
| Features | EMI filtering/RF suppression |
| Input Voltage Noise Density | 35nV/√Hz@1kHz |
| Dual Supply | -1.5V~16V |
| Single Supply | 3V~32V |
Selection Notes
- Package: SOIC-14
- Output Current: 20mA
- Number of Channels: 4
- Operating Temperature: 0℃~+70℃
- Vos – Input Offset Voltage: 3mV
Application Fit
This exact part is appropriate for designs that require a operational amplifier with the confirmed package and electrical/function parameters above. Final fit depends on the surrounding circuit, interface, thermal and mechanical requirements of the target design.
Design Considerations
Check current, power dissipation and board thermal conditions at the intended operating point rather than using the headline rating alone.
Use the exact SOIC-14 footprint/package definition when checking PCB land pattern, assembly clearance and sourcing equivalence.
