Device Overview
Qorvo RF1602TR7 is an exact-order RF switch supplied in 12-pin QFN, 2.0 x 2.0 x 0.55 mm. For substitution or design review, the strongest comparison points are Frequency Range (100 to 3500 MHz), Insertion Loss (0.3 dB), Isolation (42 dB).
Selection-Critical Data
| Parameter | Confirmed Data | Why It Matters |
|---|---|---|
| Frequency Range | 100 to 3500 MHz | Defines the operating frequency or RF band that must cover the intended signal frequencies. |
| Insertion Loss | 0.3 dB (at 1 GHz) | Defines signal loss through the RF path and therefore contributes directly to the link budget. |
| Isolation | 43 dB parameter value; 42 dB typical key-feature value at 1 GHz | Defines suppression of unwanted coupling between RF paths or switch states at the stated frequency. |
| Exact Package | 12-pin QFN, 2.0 x 2.0 x 0.55 mm | Determines PCB footprint, pinout, mechanical assembly and orderable-variant compatibility. |
| Rf Function | RF switch | Defines the device function or architecture that a compatible replacement must preserve before secondary ratings are compared. |
RF Selection Notes
For frequency range, 100 to 3500 MHz is the approved value. Defines the operating frequency or RF band that must cover the intended signal frequencies. Rf Function is RF switch. Defines the device function or architecture that a compatible replacement must preserve before secondary ratings are compared.
At 0.3 dB, the insertion loss defines signal loss through the RF path and therefore contributes directly to the link budget. Technical condition: at 1 GHz. The isolation is 42 dB; this defines suppression of unwanted coupling between RF paths or switch states at the stated frequency. Technical condition: at 1 GHz.
At 12-pin QFN, 2.0 x 2.0 x 0.55 mm, the exact package determines PCB footprint, pinout, mechanical assembly and orderable-variant compatibility.
Procurement Note
Qorvo lists RF1602 as Discontinued. End of life was announced July 6, 2021, with last time buy on January 17, 2022.
