Key Selection Information
| Selection Parameter | Confirmed Information |
|---|---|
| Channels | 4 comparators |
| Output | Open-collector outputs |
| Common Mode | Input range includes ground in single-supply applications |
| Supply | Wide-voltage standard comparator family |
| Use | Four-channel threshold, window, alarm and zero-crossing banks |
| Temperature | −25°C to +85°C exact order-code range |
| Package | SOIC (D), 14 pins |
| Packing | 2500-piece large tape and reel; marking LM239 |
Product Overview
LM239DR integrates four independent standard comparators in one SOIC-14, useful when several rails, sensors or thresholds must be supervised on one board. All four channels share supplies but retain separate open-collector outputs.
Open-collector outputs allow different pull-up logic voltage or wired alarm combination, at the cost of an external resistor and rise-time dependence on capacitance.
The exact LM239 temperature range is narrower than LM2901 industrial variants. That temperature-grade difference is more important than generic family similarity when selecting a production substitute.
For related devices, see HKEQGOO’s Comparators category.
Technical Specifications
| Parameter | Verified Information |
|---|---|
| Manufacturer | Texas Instruments |
| Exact MPN | LM239DR |
| Channels | 4 comparators |
| Output | Open-collector outputs |
| Common Mode | Input range includes ground in single-supply applications |
| Supply | Wide-voltage standard comparator family |
| Use | Four-channel threshold, window, alarm and zero-crossing banks |
| Temperature | −25°C to +85°C exact order-code range |
| Package | SOIC (D), 14 pins |
| Packing | 2500-piece large tape and reel; marking LM239 |
| Manufacturer Status | Active / Production |
| Part Marking | LM239 |
Functional Highlights
Four channels reduce BOM for multi-threshold systems
Rail monitors, heater controls and simple window detectors can be implemented with one package instead of multiple single/dual comparators.
Open collectors can share an alarm line
Several comparator outputs may be wire-ORed when the system only needs a common fault indication.
Design Considerations
- Size pull-ups for worst-case bus capacitance if outputs are wire-combined.
- Do not copy B-version offset/propagation figures onto the legacy LM239.
- Check the −25°C lower limit against the product environmental requirement.
Product Status and Exact Order Code
Manufacturer status: Active / Production
Texas Instruments lists LM239DR as Active / Production; SOIC (D), 14 pins; 2500-piece large tape and reel; −25°C to +85°C; marking LM239.
