Device Overview
AT30TS74-XM8M-T is an I2C/SMBus-compatible digital temperature sensor in an 8-lead 3 mm x 3 mm MSOP package. It operates from 1.7 V to 5.5 V and supports I2C High-Speed mode up to 3.4 MHz.
Resolution is selectable from 9 to 12 bits, corresponding to 0.5 °C down to 0.0625 °C per LSB. The exact XM8M-T ordering row is specified for -55 to 125 °C operation.
Confirmed Technical and Ordering Data
| Parameter | Confirmed value | Scope / condition |
|---|---|---|
| Sensor Type | Digital temperature sensor | Specified for this exact device/family context |
| Measurement Range Or Axes | -55 to 125 °C | Specified for this exact device/family context |
| Interface | I2C / SMBus-compatible; High-Speed mode up to 3.4 MHz | Specified for this exact device/family context |
| Supply Voltage | 1.7 to 5.5 V | Specified for this exact device/family context |
| Resolution | 9 to 12 bits | selectable |
| Resolution Step | 0.5 to 0.0625 °C/LSB | 9-bit to 12-bit modes |
| Noise Or Accuracy | ±1.0 °C typical from -20 to +100 °C; ±2.0 °C typical from -40 to +125 °C | Accuracy depends on temperature range |
| Active Current | 85 µA | typical |
| Shutdown Current | 1 µA | typical |
| Exact Package | MSOP-8, 3.00 mm x 3.00 mm XM8M | Specified for this exact device/family context |
| Temperature Grade | -55 to 125 °C | Industrial High Temperature exact ordering row |
Engineering Selection Guidance
Resolution and accuracy are different specifications. Selecting 12-bit conversion gives 0.0625 °C per LSB, but it does not make absolute temperature accuracy 0.0625 °C.
Accuracy must also retain its temperature condition: the documented typical error is ±1.0 °C from -20 to +100 °C and ±2.0 °C from -40 to +125 °C. Neither figure should be extended automatically to the full -55 to +125 °C operating range.
The 3.4 MHz value refers to I2C High-Speed mode and assumes a compatible controller and bus. The exact XM8M code selects the 8-lead 3 mm x 3 mm MSOP package, while the T suffix is the packing option.
Lifecycle and Procurement
Microchip Technology lists AT30TS74-XM8M-T / its exact base orderable as In Production. The exact package is MSOP-8 and the orderable temperature grade is -55 to 125 °C. Manufacturer lifecycle status does not state HKEQGOO stock, lead time, MOQ or final availability.
Alternative Candidates for Engineering Evaluation
The following parts are source-displayed candidates only. Verify electrical specifications, pinout, package, temperature grade, qualification and lifecycle before substitution.
- AT30TS74-XM8M-B – MICROCHIP – MSOP-8
- GX175U – GXCAS – MSOP8
- ADT75BRMZ-REEL7 – ADI – MSOP-8
- ADT75ARMZ-REEL7 – ADI – MSOP-8
- MCP9801-M/MS – MICROCHIP – MSOP-8
