Key Selection Information
| Selection Parameter | Confirmed Information |
|---|---|
| Package | SOIC-8 |
| Supply voltage | 2.7V~5.5V;2.7V~5.5V |
| Number of Channels | 2 |
| Isolation voltage | 2500 |
| CMTI(kV/us) | 25kV/us |
| Operating Temperature | -40℃~+105℃ |
| Features | Bidirectional signal isolation;Multi-voltage domain interface;Power-on reset |
Product Overview
ADUM1201ARZ-RL7 is a Analog Devices digital isolator identified by the exact orderable code ADUM1201ARZ-RL7. Its confirmed technical identity includes Supply voltage 2.7V~5.5V;2.7V~5.5V, Number of Channels 2, Isolation voltage 2500, CMTI(kV/us) 25kV/us.
The exact device is described as: 25kV/us SOIC-8 Digital Isolators. Selection should be based on the exact package and the operating conditions required by the design, rather than on a nearby family member or a generic part number.
Technical Specifications
| Parameter | Value |
|---|---|
| Package | SOIC-8 |
| Supply voltage | 2.7V~5.5V;2.7V~5.5V |
| Number of Channels | 2 |
| Isolation voltage | 2500 |
| CMTI(kV/us) | 25kV/us |
| Operating Temperature | -40℃~+105℃ |
| Features | Bidirectional signal isolation;Multi-voltage domain interface;Power-on reset |
| Propagation Delay(tpd) | 50ns |
| Number of Forward Channels | 1 |
| Number of Reverse Channels | 1 |
| Data Rate(Max) | 1Mbps |
Exact-Part Selection Insight
This device combines 2 isolated channels with 2500 Vrms isolation and 1Mbps maximum data rate. Channel direction, supply domains, PCB creepage/clearance and required working-voltage standard must be checked as a system; isolation-voltage headline value alone does not define the complete barrier design.
Selection Notes
- Package: SOIC-8
- Supply voltage: 2.7V~5.5V;2.7V~5.5V
- Number of Channels: 2
- Isolation voltage: 2500
- CMTI(kV/us): 25kV/us
Application Fit
This exact part is appropriate for designs that require a digital isolator with the confirmed package and electrical/function parameters above. Final fit depends on the surrounding circuit, interface, thermal and mechanical requirements of the target design.
Design Considerations
Confirm the available supply rail stays inside the stated operating range, including startup and transient conditions.
Use the exact SOIC-8 footprint/package definition when checking PCB land pattern, assembly clearance and sourcing equivalence.
