Procurement Snapshot
| Procurement Field | Value |
|---|---|
| Exact MPN | FAN3227TMX |
| Manufacturer | onsemi |
| Package | SOIC-8 |
| Availability | Request current stock and lead time by RFQ |
| Datasheet | Verified PDF |
Key Selection Information
| Selection Parameter | Confirmed Information |
|---|---|
| Voltage – Supply | 4.5V~18V |
| Quiescent Current | 750uA |
| Current – Output Low(IOL) | 3A |
| Current – Output High(IOH) | 3A |
| Input Logic Level – Low | 800mV~1.2V |
| Input Logic Level – High | 1.6V~2V |
| Operating Temperature | -40℃~+125℃ |
| Features | Enable shutdown |
Product Overview
FAN3227TMX is a Low Side Gate Driver IC MOSFET SOIC-8 from onsemi. The exact manufacturer order code is preserved for BOM, RFQ and incoming-inspection control. The verified package is SOIC-8, and the verified functional category is Gate Drivers. Confirmed selection data for this exact listing includes Voltage – Supply 4.5V~18V, Quiescent Current 750uA, Current – Output Low(IOL) 3A, Current – Output High(IOH) 3A.
Alternative Candidates
| MPN | Manufacturer | Package |
|---|---|---|
| FAN3226TMX | onsemi | SOIC-8 |
| FAN3217TMX | onsemi | SOIC-8 |
| FAN3216TMX | onsemi | SOIC-8 |
| FAN3229TMX | onsemi | SOIC-8 |
| FAN3227TMX-F085 | onsemi | SOIC-8 |
| FAN3224TMX | onsemi | SOIC-8 |
| FAN3224TUMX-F085 | onsemi | SOIC-8 |
| FAN3217TMX-F085 | onsemi | SOIC-8 |
| FAN3225TMX | onsemi | SOIC-8 |
| FAN3227CMX | onsemi | SOIC-8 |
| FAN3216TMX-F085 | onsemi | SOIC-8 |
| FAN3225TMX-F085 | onsemi | SOIC-8 |
| FAN3223TMX-F085 | onsemi | SOIC-8 |
| FAN3214TMX-F085 | onsemi | SOIC-8 |
| FAN3226TMX-F085 | onsemi | SOIC-8 |
| FAN3214TMX | onsemi | SOIC-8 |
| FAN3213TMX-F085 | onsemi | SOIC-8 |
| FAN3223CMX-F085 | onsemi | SOIC-8 |
| FAN3226CMX-F085 | onsemi | SOIC-8 |
These candidates are listed by LCSC. Verify electrical characteristics, pinout, package, qualification and application requirements before substitution.
Quality & RFQ Support
For quotation or inspection requirements, provide the exact MPN, quantity, destination, target Date Code if applicable, and any requested third-party testing before shipment.
