Key Selection Information
| Selection Parameter | Confirmed Information |
|---|---|
| Package | SOT-23-5 |
| Operating/input voltage | 10V |
| Output Voltage | 1.2V~5.5V |
| Output Current | 100mA |
| Operating Temperature | -40℃~+125℃@(Tj) |
| Number of Outputs | 1 |
| Supply Current (Iq) | 17uA |
Product Overview
TPS76901DBVT is a Texas Instruments linear regulator (LDO) identified by the exact orderable code TPS76901DBVT. Its confirmed technical identity includes Operating/input voltage 10V, Output Voltage 1.2V~5.5V, Output Current 100mA, Operating Temperature -40℃~+125℃@(Tj).
The exact device is described as: 1.2V~5.5V Positive Adjustable SOT-23-5 Voltage Regulators – Linear, Low Drop Out (LDO) Regulators. Selection should be based on the exact package and the operating conditions required by the design, rather than on a nearby family member or a generic part number.
Technical Specifications
| Parameter | Value |
|---|---|
| Package | SOT-23-5 |
| Operating/input voltage | 10V |
| Output Voltage | 1.2V~5.5V |
| Output Current | 100mA |
| Operating Temperature | -40℃~+125℃@(Tj) |
| Number of Outputs | 1 |
| Supply Current (Iq) | 17uA |
| Output Configuration | Positive |
| Features | Enable control;Over Current Protection;Thermal shutdown |
| Output Type | Adjustable |
Exact-Part Selection Insight
The exact part combines an output-voltage condition of 1.2V~5.5V with an output-current rating of 100mA. Verify the stated test/operating conditions and thermal path before treating both limits as simultaneously achievable in the final circuit.
Selection Notes
- Package: SOT-23-5
- Operating/input voltage: 10V
- Output Voltage: 1.2V~5.5V
- Output Current: 100mA
- Operating Temperature: -40℃~+125℃@(Tj)
Application Fit
This exact part is appropriate for designs that require a linear regulator (LDO) with the confirmed package and electrical/function parameters above. Final fit depends on the surrounding circuit, interface, thermal and mechanical requirements of the target design.
Design Considerations
Confirm the available supply rail stays inside the stated operating range, including startup and transient conditions.
Check current, power dissipation and board thermal conditions at the intended operating point rather than using the headline rating alone.
Use the exact SOT-23-5 footprint/package definition when checking PCB land pattern, assembly clearance and sourcing equivalence.
