Device Overview
Designed as a RF switch, Qorvo QPC6082TR7 uses the 14-pad QFN, 2.0 x 2.0 mm package. For substitution or design review, the strongest comparison points are Frequency Range (700 MHz to 2700 MHz), Insertion Loss (0.4 dB), Isolation (31 dB).
Selection-Critical Data
| Parameter | Confirmed Data | Why It Matters |
|---|---|---|
| Frequency Range | 5 to 6000 MHz parameter range; optimized for 700 to 2700 MHz | Defines the operating frequency or RF band that must cover the intended signal frequencies. |
| Insertion Loss | 0.4 dB | Defines signal loss through the RF path and therefore contributes directly to the link budget. |
| Isolation | 31 dB | Defines suppression of unwanted coupling between RF paths or switch states at the stated frequency. |
| Exact Package | 14-pad QFN, 2.0 x 2.0 mm | Determines PCB footprint, pinout, mechanical assembly and orderable-variant compatibility. |
| Rf Function | RF switch | Defines the device function or architecture that a compatible replacement must preserve before secondary ratings are compared. |
| Supply Voltage | +2.4 / +2.85 / +4.5 V (Min / Typ / Max) | Defines compatibility with the available board power rail and required bias range. |
| Supply Current | 0.08 mA (80 uA) | Defines DC power and thermal burden on the bias or supply rail. |
RF Selection Notes
The manufacturer parameter range is 5 to 6000 MHz, with performance optimized for 700 to 2700 MHz cellular applications. The rf function is RF switch; this defines the device function or architecture that a compatible replacement must preserve before secondary ratings are compared.
At 0.4 dB, the insertion loss defines signal loss through the RF path and therefore contributes directly to the link budget. 31 dB is the stated isolation value. Defines suppression of unwanted coupling between RF paths or switch states at the stated frequency.
+2.4 / +2.85 / +4.5 V is the stated supply voltage value. Defines compatibility with the available board power rail and required bias range. Technical condition: Min / Typ / Max. For supply current, the current Qorvo parameter value is 0.08 mA (80 uA). Defines DC power and thermal burden on the bias or supply rail.
At 14-pad QFN, 2.0 x 2.0 mm, the exact package determines PCB footprint, pinout, mechanical assembly and orderable-variant compatibility.
Procurement Note
Qorvo lists QPC6082 as Discontinued. End of life was announced May 29, 2020, with last time buy on December 9, 2020.
