Key Selection Information
| Selection Parameter | Confirmed Information |
|---|---|
| Function | Regulated isolated DC/DC converter |
| Input | 3.0 V to 3.6 V |
| Output | 3.3 V |
| Output power | 0.25 W |
| Isolation | 3 kVDC |
| Package | SOICW-16 |
| Product status | Active exact MPS listing |
Product Overview
The MID02W0303AGY-3R-Z is an active MPS regulated isolated DC/DC converter providing 3.3 V output from a 3.0–3.6 V input with 3 kVDC isolation. It integrates the switching power stage, transformer and feedback into a wide-body SOIC module.
This device is intended for low-power isolated bias rails rather than non-isolated regulation. PCB creepage/clearance around the isolation barrier remains part of the safety design.
Technical Specifications
| Parameter | Confirmed Information |
|---|---|
| Input voltage | 3.0–3.6 V |
| Output voltage | 3.3 V |
| Maximum output power | 0.25 W |
| Isolation voltage | 3 kVDC |
| Integration | MOSFET, transformer and feedback integrated |
| Package | SOICW-16 |
| Product status | Active |
Design Considerations
Maintain the manufacturer-recommended isolation keepout and creepage around primary/secondary pins. Copper or test pads across the barrier can defeat the module’s isolation rating.
At 0.25 W output, available current is limited; verify startup and transient load against the converter’s regulation and protection behavior.
