Key Selection Information
| Selection Parameter | Confirmed Information |
|---|---|
| Package | SOT-23-6 |
| Operating/input voltage | 4.5V~17V |
| Output Voltage | 765mV~7V |
| Output Current | 2A |
| Frequency – Switching | 650kHz |
| Topology | Buck |
| Operating Temperature | -40℃~+85℃@(TA) |
Product Overview
TPS562200DDCR is a Texas Instruments DC-DC switching regulator identified by the exact orderable code TPS562200DDCR. Its confirmed technical identity includes Operating/input voltage 4.5V~17V, Output Voltage 765mV~7V, Output Current 2A, Frequency – Switching 650kHz.
The exact device is described as: 650kHz Step-down type Adjustable 765mV~7V 2A SOT-23-6 Voltage Regulators – DC DC Switching Regulators. Selection should be based on the exact package and the operating conditions required by the design, rather than on a nearby family member or a generic part number.
Technical Specifications
| Parameter | Value |
|---|---|
| Package | SOT-23-6 |
| Operating/input voltage | 4.5V~17V |
| Output Voltage | 765mV~7V |
| Output Current | 2A |
| Frequency – Switching | 650kHz |
| Topology | Buck |
| Operating Temperature | -40℃~+85℃@(TA) |
| Function | Step-down type |
| Number of Outputs | 1 |
| Features | Cycle-by-cycle current limiting;Hiccup current limiting;Light load efficient mode;Overcurrent Protection |
| Output Type | Adjustable |
| Switch tube (built-in/external) | Built-in |
| Quiescent Current | 330uA |
Exact-Part Selection Insight
This regulator combines a 4.5V~17V operating/input range, 2A output-current rating and 650kHz switching frequency. Those three values interact with inductor/diode or FET selection, capacitor ripple requirements and thermal margin; the current rating should not be evaluated independently of input voltage and switching conditions.
Selection Notes
- Package: SOT-23-6
- Operating/input voltage: 4.5V~17V
- Output Voltage: 765mV~7V
- Output Current: 2A
- Frequency – Switching: 650kHz
Application Fit
This exact part is appropriate for designs that require a DC-DC switching regulator with the confirmed package and electrical/function parameters above. Final fit depends on the surrounding circuit, interface, thermal and mechanical requirements of the target design.
Design Considerations
Confirm the available supply rail stays inside the stated operating range, including startup and transient conditions.
Check current, power dissipation and board thermal conditions at the intended operating point rather than using the headline rating alone.
Use the exact SOT-23-6 footprint/package definition when checking PCB land pattern, assembly clearance and sourcing equivalence.
