Key Selection Information
| Selection Parameter | Confirmed Information |
|---|---|
| Package | PDIP-8-300mil |
| Supply voltage | 4.5V~5.5V |
| Data Rate | 1Mbps |
| Operating Temperature | -40℃~+125℃ |
| Type | CAN Transceiver |
| Features | Low-power mode;Wake-up function;Short-Circuit Protection;Thermal shutdown protection;Undervoltage Protection;TXD dominant timeout;ESD protection |
| Supply Current | 75mA |
Product Overview
MCP2551-E/P is a Microchip Technology interface transceiver identified by the exact orderable code MCP2551-E/P. Its confirmed technical identity includes Supply voltage 4.5V~5.5V, Data Rate 1Mbps, Operating Temperature -40℃~+125℃, Type CAN Transceiver.
The exact device is described as: 4.5V~5.5V CAN Transceiver 1Mbps PDIP-8-300mil Drivers, Receivers, Transceivers. Selection should be based on the exact package and the operating conditions required by the design, rather than on a nearby family member or a generic part number.
Technical Specifications
| Parameter | Value |
|---|---|
| Package | PDIP-8-300mil |
| Supply voltage | 4.5V~5.5V |
| Data Rate | 1Mbps |
| Operating Temperature | -40℃~+125℃ |
| Type | CAN Transceiver |
| Features | Low-power mode;Wake-up function;Short-Circuit Protection;Thermal shutdown protection;Undervoltage Protection;TXD dominant timeout;ESD protection |
| Supply Current | 75mA |
| Quiescent Supply Current | 465uA |
Exact-Part Selection Insight
The exact transceiver/interface part is rated for 1Mbps data rate from 4.5V~5.5V supplies. Bus termination, common-mode range, node count and logic-side voltage must match the target network; a protocol-family label by itself is not enough to establish substitution compatibility.
Selection Notes
- Package: PDIP-8-300mil
- Supply voltage: 4.5V~5.5V
- Data Rate: 1Mbps
- Operating Temperature: -40℃~+125℃
- Type: CAN Transceiver
Application Fit
This exact part is appropriate for designs that require a interface transceiver with the confirmed package and electrical/function parameters above. Final fit depends on the surrounding circuit, interface, thermal and mechanical requirements of the target design.
Design Considerations
Confirm the available supply rail stays inside the stated operating range, including startup and transient conditions.
Verify interface voltage levels, bus topology and timing/data-rate requirements against the rest of the system.
Use the exact PDIP-8-300mil footprint/package definition when checking PCB land pattern, assembly clearance and sourcing equivalence.
