Procurement Snapshot
| Procurement Field | Value |
|---|---|
| Exact MPN | ADM202EARNZ-REEL7 |
| Manufacturer | Analog Devices |
| Package | SOIC-16 |
| Availability | Contact for current stock and lead time |
| Datasheet | Verified PDF |
Key Selection Information
| Selection Parameter | Confirmed Information |
|---|---|
| Type | Transceiver |
| Voltage – Supply | 5V |
| Data Rate | 230Kbps |
| ESD Protect | ±15kV |
| Number of Drivers | 2 |
| Number of Receivers | 2 |
| Operating Temperature | -40℃~+85℃ |
| Package | SOIC-16 |
Product Overview
ADM202EARNZ-REEL7 is a EMI/EMC-Compliant, ±15 kV, ESD-Protected RS-232 Line Drivers/Receivers ADM202E/ADM1181A from Analog Devices. The exact order code is preserved for BOM, RFQ and incoming-inspection control. The verified package for this listing is SOIC-16. For engineering selection, the most relevant confirmed values include Type Transceiver, Voltage – Supply 5V, Data Rate 230Kbps, ESD Protect ±15kV.
Application Fit
- Industrial and diagnostic serial ports
- Embedded RS-232 interfaces
- Instrumentation communication links
Design Considerations
- Confirm supply range, channel count and data-rate requirement.
- Place required charge-pump capacitors close to the device when applicable.
- Verify the exact package and pinout before replacing a related family member.
Alternative Candidates for Engineering Evaluation
| MPN | Manufacturer | Package |
|---|---|---|
| MAX232EESE+T | MAXIM | SOIC-16 |
| HG202EIM/TR | HGSEMI | SOP-16 |
| GM232ESA | GATEMODE | SOP-16 |
| MAX232ECDR | TI | SOIC-16 |
| LT1381IS#PBF | ADI | SO-16 |
| MAX202ECSE+T | MAXIM | SOP-16 |
| LT1781CS#PBF | ADI | SO-16 |
| MAX232ESE-MS | MSKSEMI | SOP-16 |
| SP232EEN-MS | MSKSEMI | SOP-16 |
| ADM202EARNZ | ADI | SOIC-16 |
| MAX202ESE+T | MAXIM | SO-16 |
| MAX232ESE+ | MAXIM | SOIC-16 |
| HIN202EIBNZ | RENESAS | SOIC-16 |
| MAX232EESE+ | MAXIM | SO-16 |
| HIN232ACBNZ-T | RENESAS | SOIC-16 |
| LT1781IS#PBF | ADI | SO-16 |
| LT1781CS#TRPBF | ADI | SO-16 |
| LT1781IS#TRPBF | ADI | SO-16 |
| LT1381IS#TRPBF | ADI | SO-16 |
| LT1381IS | ADI | SOIC-16 |
These candidates are listed by LCSC. Verify electrical characteristics, pinout, package, qualification and application requirements before substitution.
For purchasing the same ADM202EARNZ 16-lead SOIC transceiver under a distinct manufacturer order code, compare ADM202EARNZ-REEL. Analog Devices lists both -REEL and -REEL7 orderables; confirm the required reel format, quantity and incoming-label code before placing a BOM order rather than assuming identical packing.
Quality & RFQ Support
For quotation or inspection requirements, provide the exact MPN, quantity, destination, target Date Code if applicable, and any requested third-party testing before shipment.
