Product Overview
2EP130RXTMA1 is the active tape-and-reel OPN of Infineon's 2EP130R full-bridge transformer driver. It is designed to drive a transformer that generates isolated gate-driver supply rails for IGBT, GaN and SiC power stages, rather than driving the power transistor gate directly.
The device is a 5 W, 20 V class transformer driver with adjustable 50-695 kHz oscillator frequency and 10-50% duty cycle. Duty-cycle adjustment is especially relevant when an asymmetric isolated gate-drive supply is required.
Confirmed Electrical and Ordering Data
| Parameter | Confirmed value | Scope / condition |
|---|---|---|
| Driver Function | Full-bridge transformer driver | isolated gate-driver power-supply transformer drive |
| Channels Or Topology | 2-channel full bridge | full-bridge configuration |
| Drive Current Or Load | 5 W output-power class | manufacturer headline output power |
| Supply Voltage | Up to 20 V | voltage class / supply headline |
| Oscillator Frequency | 50 to 695 kHz | adjustable internal oscillator frequency |
| Duty Cycle | 10 to 50 % | adjustable duty-cycle range |
| Synchronization Delay | 280 ns | synchronization propagation delay |
| Protection | Adjustable OCP, short-circuit protection, overtemperature protection, UVLO | integrated protection set |
| Package | PG-TSSOP-8 | exact orderable package |
| Packing | Tape and reel, 5000 per reel | exact OPN packing |
Engineering Selection Guidance
The 5 W figure is the transformer-driver output-power class, not gate current delivered directly to an IGBT, SiC MOSFET or GaN transistor.
Use the 50-695 kHz range as the oscillator-frequency range; the malformed low-frequency duplicate sometimes shown in product selectors should not replace the datasheet's kHz range.
Transformer turns ratio, isolation rating, rectifier losses and gate-driver load determine the actual isolated-rail voltages and available secondary-side power.
Lifecycle and Ordering Context
Infineon Technologies currently lists the exact orderable 2EP130RXTMA1 as Active. The verified package is PG-TSSOP-8 and the packing form is Tape and reel, 5000 per reel. Lifecycle information is for sourcing and design planning; it does not state HKEQGOO stock, lead time or delivery availability.
