Key Selection Information
| Selection Parameter | Confirmed Information |
|---|---|
| Function | High-speed ultrasound return-to-zero pulser |
| Channels | 8 |
| Output voltage class | ±60 V |
| Peak output current | ±1 A |
| Package | 56-lead VQFN |
| Environmental suffix | Lead-free / RoHS compliant |
| Packing | 250 per tray |
| Exact order code | HV7350K6-G |
Product Overview
The HV7350K6-G is Microchip’s eight-channel high-voltage ultrasound return-to-zero pulser in a 56-lead VQFN package. It is designed to drive multiple ultrasound transducer channels with high-speed bipolar pulses, supporting output amplitudes up to the ±60 V class and peak current up to ±1 A.
The exact K6-G order code defines both the package and environmental option. K6 is the 56-lead VQFN and G identifies the lead-free/RoHS-compliant package. With no M937 media suffix, this exact device is supplied in the tray configuration rather than reel packaging.
Technical Specifications
| Parameter | Confirmed Information |
|---|---|
| Application | Ultrasound transmit pulser |
| Channel count | 8 |
| Pulser type | Return-to-zero |
| Output voltage capability | ±60 V class |
| Peak output current | ±1 A |
| Package | 56-lead VQFN |
| Package code | K6 |
| Environmental code | G, lead-free/RoHS compliant |
| Standard media | 250 per tray |
Design Considerations
High-voltage ultrasound pulsers place strong demands on supply decoupling, ground return and transducer trace layout. Keep high-current pulse paths short and segregate sensitive receive circuitry from transmit switching edges.
The tray and reel order codes are different catalog items. For automated production requiring tape-and-reel, use the appropriate media suffix rather than assuming HV7350K6-G itself is supplied on reel.
