Procurement Snapshot
| Procurement Field | Value |
|---|---|
| Exact MPN | ADM1166ASUZ-REEL7 |
| Manufacturer | Analog Devices |
| Package | LQFP-48(7×7) |
| Availability | Contact for current stock and lead time |
| Datasheet | Verified PDF |
Key Selection Information
| Selection Parameter | Confirmed Information |
|---|---|
| Operating Voltage | 3V~14.4V |
| Reset Timeout | 10us |
| Function | Watchdog timer;Manual reset input |
| Reset Active Level | Active Low |
| Output Type | Push-pull |
| Operating Temperature | -40℃~+85℃ |
| Package | LQFP-48(7×7) |
| Number of Voltages Monitored | 10 |
Product Overview
ADM1166ASUZ-REEL7 is a Super Sequencer with Margining Control and Nonvolatile Fault Recording from Analog Devices. The exact order code is preserved for BOM, RFQ and incoming-inspection control. The verified package for this listing is LQFP-48(7×7). For engineering selection, the most relevant confirmed values include Operating Voltage 3V~14.4V, Reset Timeout 10us, Function Watchdog timer;Manual reset input, Reset Active Level Active Low.
Application Fit
- MCU/processor power supervision
- Power sequencing and fault monitoring
- Industrial and embedded control systems
Design Considerations
- Verify threshold, reset polarity and timeout against the processor or rail requirements.
- Check watchdog/manual-reset behavior in the exact suffix variant.
- Review supply current and operating-temperature limits for the target system.
Alternative Candidates for Engineering Evaluation
| MPN | Manufacturer | Package |
|---|---|---|
| ADM1166ASUZ | ADI | TQFP-48(7×7) |
| ADM1166ASUZ-REEL | ADI | TQFP-48(7×7) |
These candidates are listed by LCSC. Verify electrical characteristics, pinout, package, qualification and application requirements before substitution.
Quality & RFQ Support
For quotation or inspection requirements, provide the exact MPN, quantity, destination, target Date Code if applicable, and any requested third-party testing before shipment.
