Key Selection Information
| Selection Parameter | Confirmed Information |
|---|---|
| Package | SOIC-16 |
| Supply voltage | 2.5V~5.5V |
| Output Power | 5Wx2@2Ω |
| Speaker Channels | 2-Channel |
| Operating Temperature | -40℃~+85℃ |
| Quiescent Current | 10mA |
| Features | Filterless architecture;Enable/shutdown function;Automatic mute/no-noise switch |
Product Overview
PAM8406DR is a Diodes Incorporated audio amplifier identified by the exact orderable code PAM8406DR. Its confirmed technical identity includes Supply voltage 2.5V~5.5V, Output Power 5Wx2@2Ω, Speaker Channels 2-Channel, Operating Temperature -40℃~+85℃.
The exact device is described as: 10mA 2.5V~5.5V 2-Channel 5Wx2@2Ω SOIC-16 Audio Amplifiers. Selection should be based on the exact package and the operating conditions required by the design, rather than on a nearby family member or a generic part number.
Technical Specifications
| Parameter | Value |
|---|---|
| Package | SOIC-16 |
| Supply voltage | 2.5V~5.5V |
| Output Power | 5Wx2@2Ω |
| Speaker Channels | 2-Channel |
| Operating Temperature | -40℃~+85℃ |
| Quiescent Current | 10mA |
| Features | Filterless architecture;Enable/shutdown function;Automatic mute/no-noise switch |
| Total Harmonic Distortion + Noise (THD+N) | 0.11% |
| Number of Inputs | 2 Single-Ended Inputs |
| Signal-to-Noise Ratio | 90dB |
| Efficiency | 90% |
| Class | Class AB;Class D |
| Power Supply Rejection Ratio (PSRR) | -70dB |
Exact-Part Selection Insight
The stated 5Wx2@2Ω output-power condition is tied to the amplifier’s 2.5V~5.5V supply range and the load condition embedded in that rating. Thermal design, speaker impedance and available supply voltage must be evaluated together before using the headline wattage as a continuous design target.
Selection Notes
- Package: SOIC-16
- Supply voltage: 2.5V~5.5V
- Output Power: 5Wx2@2Ω
- Speaker Channels: 2-Channel
- Operating Temperature: -40℃~+85℃
Application Fit
This exact part is appropriate for designs that require a audio amplifier with the confirmed package and electrical/function parameters above. Final fit depends on the surrounding circuit, interface, thermal and mechanical requirements of the target design.
Design Considerations
Confirm the available supply rail stays inside the stated operating range, including startup and transient conditions.
Check current, power dissipation and board thermal conditions at the intended operating point rather than using the headline rating alone.
Use the exact SOIC-16 footprint/package definition when checking PCB land pattern, assembly clearance and sourcing equivalence.
