Key Selection Information
| Selection Parameter | Confirmed Information |
|---|---|
| Manufacturer | MPS |
| Exact MPN | MA730GQ-Z |
| Product Category | Position Sensors |
| Package | QFN-16(3×3) |
| Packing | 5,000 pcs/reel |
| Type | Magnetic rotary position sensor |
| Interface | SPI; SSI |
| Operating Voltage | 3.3V |
| Operating Current | 11.7mA |
Product Overview
14-bit digital contactless angle sensor with ABZ incremental and PWM outputs.
The device is suited where digital angle data plus incremental/PWM compatibility is required; mechanical magnet alignment remains application-critical.
Technical Specifications
| Parameter | Verified Information |
|---|---|
| Manufacturer | MPS |
| Exact MPN | MA730GQ-Z |
| Functional Category | Position Sensors |
| Package | QFN-16(3×3) |
| Packing | 5,000 pcs/reel |
| Source Catalog ID | C161798 |
| Type | Magnetic rotary position sensor |
| Interface | SPI; SSI |
| Operating Voltage | 3.3V |
| Operating Current | 11.7mA |
| Manufacturer Status | Active. |
Selection Notes
Resolution; ABZ/PWM output use; shaft configuration; magnetic-field dependence; refresh rate/noise.
Match the interface and supply to the host controller, then verify resolution/latency and the required magnet geometry for the mechanical stack-up.
Manufacturer Decision-Relevant Notes
14-bit; digital output; contactless sensing; ABZ incremental outputs; PWM output; side-shaft and end-of-shaft evaluation configurations are supported; communication kit/software required for evaluation.
Design Considerations
- Validate magnet diameter/pole orientation and air gap; verify ABZ/PWM timing; check SPI/communication configuration; evaluate noise and refresh rate; verify thermal/supply limits from the datasheet.
Application Fit
Servo and rotary position sensing; BLDC commutation; encoder replacement are supported by the MagAlpha evaluation ecosystem.
