Key Selection Information
| Selection Parameter | Confirmed Information |
|---|---|
| Manufacturer | MPS |
| Exact MPN | MA704GQ-Z |
| Product Category | Position Sensors |
| Package | QFN-16(3×3) |
| Packing | 5,000 pcs/reel |
Product Overview
10-bit digital contactless angle sensor with ABZ incremental and PWM outputs.
MA704 is a lower-resolution, high-speed digital angle option where ABZ/PWM compatibility matters more than maximum angular resolution.
Technical Specifications
| Parameter | Verified Information |
|---|---|
| Manufacturer | MPS |
| Exact MPN | MA704GQ-Z |
| Functional Category | Position Sensors |
| Package | QFN-16(3×3) |
| Packing | 5,000 pcs/reel |
| Source Catalog ID | C29713698 |
| Manufacturer Status | Active. |
Selection Notes
Resolution; ABZ pulse count; PWM use; shaft configuration; speed and magnetic-field range.
Match the interface and supply to the host controller, then verify resolution/latency and the required magnet geometry for the mechanical stack-up.
Manufacturer Decision-Relevant Notes
10-bit absolute-angle resolution; SPI interface; 8-bit ABZ quadrature interface; programmable ABZ output from 1 to 64 pulses/turn; 10-bit PWM output; 3.3V, 12mA supply; up to 60,000rpm stated speed capability.
Design Considerations
- Validate magnet geometry and air gap; configure zero angle and ABZ pulses/turn; verify PWM frequency/duty interpretation; check SPI timing; verify supply decoupling and thermal limits.
Application Fit
Servo/rotary position sensing, encoder replacement, BLDC rotor-position sensing, and magnetic diagnostics.
Exact Variant and Procurement Notes
MPS lists MA704GQ-P and MA704GQ-Z as the same part; P and Z indicate reel size. Package: QFN-16, 3mm × 3mm; operating temperature: -40°C to +125°C; 5,000 per reel.
Manufacturer Resources
Quality & Verification Support
Third-party inspection or testing can be arranged according to customer requirements. Testing fees are borne by the buyer. Additional verification requirements can be discussed before shipment. Physical product, label, packaging, and Date Code photos may be provided where appropriate.
Request a Quote
For MA704GQ-Z quotation, provide the exact MPN, required quantity, destination, target Date Code if applicable, and any inspection or testing requirements.
