Key Selection Information
| Selection Parameter | Confirmed Information |
|---|---|
| Function | 3-line to 8-line decoder/demultiplexer |
| Logic Family | LS-TTL |
| Supply | 5 V-class TTL operation |
| Outputs | 8 active-low decoded outputs |
| Enable | Three enable inputs for cascading/strobes |
| Use Case | Legacy TTL address/chip-select decode |
| Package | SOIC (D), 16 pins |
| Packing | Large tape and reel |
Product Overview
SN74LS138DR is the LS-TTL version of the classic 138 one-of-eight decoder. It is relevant when a legacy 5 V board, timing model or input/output loading has already been qualified around LS-TTL behavior.
Although SN74HC138 performs the same Boolean decode function, it uses CMOS electrical characteristics and a wider supply range. Replacing LS with HC should therefore verify TTL input thresholds, output loading, edge/timing and supply-current assumptions rather than relying only on pin/function similarity.
The DR order code is the SOIC large-reel production format, retaining a familiar leaded footprint for serviceable legacy logic assemblies.
For related devices, see HKEQGOO’s Signal Switches, Multiplexers, Decoders category.
Technical Specifications
| Parameter | Verified Information |
|---|---|
| Manufacturer | Texas Instruments |
| Exact MPN | SN74LS138DR |
| Function | 3-line to 8-line decoder/demultiplexer |
| Logic Family | LS-TTL |
| Supply | 5 V-class TTL operation |
| Outputs | 8 active-low decoded outputs |
| Enable | Three enable inputs for cascading/strobes |
| Use Case | Legacy TTL address/chip-select decode |
| Package | SOIC (D), 16 pins |
| Packing | Large tape and reel |
| Manufacturer Status | Active / Production |
| Part Marking | LS138 family marking per TI addendum |
Functional Highlights
Legacy electrical compatibility can be the real reason to keep LS138
Mature systems may depend on LS-TTL input thresholds/output loading or qualified timing. A newer CMOS part is not automatically a risk-free substitute.
Three enable pins make 138 devices useful as address-strobe gates
The decoder can be disabled globally or cascaded into larger address maps without adding separate AND/OR gates.
Design Considerations
- Treat HC/LS substitutions as an electrical-interface change even if the truth table and pinout match.
- Check fan-out and VOL/VOH requirements of the actual legacy loads.
- Preserve active-low chip-select timing during power-up/reset.
Product Status and Exact Order Code
Manufacturer status: Active / Production
Texas Instruments lists SN74LS138DR as Active / Production exact SN74LS138DR SOIC-16 large-reel order code per current TI addendum.
