Key Selection Information
| Selection Parameter | Confirmed Information |
|---|---|
| Package | WQFN-32-EP(5×5) |
| Supply voltage | 6V~60V |
| Number of Channels | 6 |
| Operating Temperature | -40℃~+125℃ |
| Driven Configuration | Three Phase |
| Features | Enable shutdown;Dead-time control;Overcurrent Protection;Charge pump boost |
| Supply Current (Iq) | 12uA |
Product Overview
DRV8320SRTVR is a Texas Instruments motor driver identified by the exact orderable code DRV8320SRTVR. Its confirmed technical identity includes Supply voltage 6V~60V, Number of Channels 6, Operating Temperature -40℃~+125℃, Driven Configuration Three Phase.
The exact device is described as: Three Phase 6V~60V MOSFET 1A 2A WQFN-32-EP(5×5) Motor Drivers, Controllers. Selection should be based on the exact package and the operating conditions required by the design, rather than on a nearby family member or a generic part number.
Technical Specifications
| Parameter | Value |
|---|---|
| Package | WQFN-32-EP(5×5) |
| Supply voltage | 6V~60V |
| Number of Channels | 6 |
| Operating Temperature | -40℃~+125℃ |
| Driven Configuration | Three Phase |
| Features | Enable shutdown;Dead-time control;Overcurrent Protection;Charge pump boost |
| Supply Current (Iq) | 12uA |
| Load Type | MOSFET |
| Input Logic Level – High | 1.5V~5.5V |
| Current – Output High(IOH) | 1A |
| Input Logic Level – Low | 0V~800mV |
| Current – Output Low(IOL) | 2A |
Selection Notes
- Package: WQFN-32-EP(5×5)
- Supply voltage: 6V~60V
- Number of Channels: 6
- Operating Temperature: -40℃~+125℃
- Driven Configuration: Three Phase
Application Fit
This exact part is appropriate for designs that require a motor driver with the confirmed package and electrical/function parameters above. Final fit depends on the surrounding circuit, interface, thermal and mechanical requirements of the target design.
Design Considerations
Confirm the available supply rail stays inside the stated operating range, including startup and transient conditions.
Use the exact WQFN-32-EP(5×5) footprint/package definition when checking PCB land pattern, assembly clearance and sourcing equivalence.
Related Engineering Resources
- Datasheet — verified HKEQGOO-hosted technical document for this exact product identity.
Alternative Parts
The following source-displayed parts may be useful for engineering comparison. They are not claimed to be drop-in replacements; verify electrical ratings, package, pinout, lifecycle, and application conditions before substitution.
- DRV8320HRTVR — TI; WQFN-32-EP(5×5)
- DRV8320HRTVT — TI; WQFN-32-EP(5×5)
Quality & Verification Support
Third-party inspection or testing can be arranged according to customer requirements. Testing fees are borne by the buyer. Additional verification requirements can be discussed before shipment. After an order is placed, physical product, label, packaging, and Date Code photos may be provided where appropriate.
Request a Quote
To request a quotation, provide the manufacturer part number, required quantity, destination, target Date Code if applicable, and any testing or inspection requirements.
