Key Selection Information
| Selection Parameter | Confirmed Information |
|---|---|
| Device type | Dual Schottky switching diode |
| Configuration | Two independent diodes |
| Reverse voltage | 40 V |
| Average current | 120 mA per diode |
| Maximum forward voltage | 1 V at 40 mA class |
| Reverse leakage | 10 µA at 40 V class |
| Package | SOT-143B |
| Packing | ,215 tape-and-reel |
| Product status | Active |
Product Overview
BAS40-07,215 is a Nexperia dual independent Schottky diode in a four-pin SOT-143B package. Each junction is electrically accessible separately, unlike the series-connected BAS40-04 configuration.
The device is intended for high-speed switching and voltage-clamping applications where two low-capacitance Schottky junctions are needed in one small package.
Technical Specifications
| Parameter | Confirmed Information |
|---|---|
| Diodes | 2 |
| Configuration | Independent |
| Reverse voltage | 40 V |
| Current | 120 mA per diode |
| Technology | Schottky |
| Package | SOT-143B |
| Junction temperature | 150°C max |
| Exact orderable | BAS40-07,215 |
-04 vs -07 Topology
BAS40-07 provides two isolated diodes; BAS40-04 connects its diodes in series. These variants are not schematic substitutes even when voltage and current ratings match.
Manufacturer Resource
Quality & Verification Support
Exact -07 independent topology, ,215 packing code, SOT-143B package and lot/date information can be reviewed before shipment.
Request a Quote
Request BAS40-07,215 exactly and include quantity, date-code and traceability requirements.
