Key Selection Information
| Selection Parameter | Confirmed Information |
|---|---|
| Package | SOIC-8-150mil |
| Supply voltage | 4.75V~5.25V |
| Data Rate | 250Kbps |
| Operating Temperature | -40℃~+85℃ |
| Type | Transceiver |
| Number of Nodes | 32 |
| ESD Protect | ±15kV |
Product Overview
ADM483EARZ-REEL is a Analog Devices interface transceiver identified by the exact orderable code ADM483EARZ-REEL. Its confirmed technical identity includes Supply voltage 4.75V~5.25V, Data Rate 250Kbps, Operating Temperature -40℃~+85℃, Type Transceiver.
The exact device is described as: 4.75V~5.25V Transceiver 250Kbps 32 SOIC-8-150mil Drivers, Receivers, Transceivers. Selection should be based on the exact package and the operating conditions required by the design, rather than on a nearby family member or a generic part number.
Technical Specifications
| Parameter | Value |
|---|---|
| Package | SOIC-8-150mil |
| Supply voltage | 4.75V~5.25V |
| Data Rate | 250Kbps |
| Operating Temperature | -40℃~+85℃ |
| Type | Transceiver |
| Number of Nodes | 32 |
| ESD Protect | ±15kV |
| Communication Mode | Half-Duplex |
| Number of Drivers | 1 |
| Features | Tx/Rx enable;Enable shutdown;Overcurrent Protection;Low-power mode;Thermal shutdown protection |
| Number of Receivers | 1 |
| Quiescent Supply Current | 36uA |
Exact-Part Selection Insight
The exact transceiver/interface part is rated for 250Kbps data rate from 4.75V~5.25V supplies. Bus termination, common-mode range, node count and logic-side voltage must match the target network; a protocol-family label by itself is not enough to establish substitution compatibility.
Selection Notes
- Package: SOIC-8-150mil
- Supply voltage: 4.75V~5.25V
- Data Rate: 250Kbps
- Operating Temperature: -40℃~+85℃
- Type: Transceiver
Application Fit
This exact part is appropriate for designs that require a interface transceiver with the confirmed package and electrical/function parameters above. Final fit depends on the surrounding circuit, interface, thermal and mechanical requirements of the target design.
Design Considerations
Confirm the available supply rail stays inside the stated operating range, including startup and transient conditions.
Verify interface voltage levels, bus topology and timing/data-rate requirements against the rest of the system.
Use the exact SOIC-8-150mil footprint/package definition when checking PCB land pattern, assembly clearance and sourcing equivalence.
