Key Selection Information
| Selection Parameter | Confirmed Information |
|---|---|
| Manufacturer | Winbond |
| Exact MPN | W25M512JVEIQ |
| Memory Type | SPI NOR Flash memory |
| Memory Density | 512 Mbit |
| Interface | SPI |
| Clock Frequency | 104 MHz |
| Operating Voltage | 2.7 V to 3.6 V |
| Package | WSON-8-EP(6×8) |
Product Overview
W25M512JVEIQ is a 512 Mbit, SPI NOR Flash memory, up to 104 MHz, for 2.7 V to 3.6 V, supplied in WSON-8-EP(6×8).
Its useful comparison axes are the verified density, supply range, interface/clock combination and exact package footprint shown on this page.
Technical Specifications
| Parameter | Verified Information |
|---|---|
| Manufacturer | Winbond |
| Exact MPN | W25M512JVEIQ |
| Functional Category | NOR FLASH |
| Memory Type | SPI NOR Flash memory |
| Package | WSON-8-EP(6×8) |
| Interface | SPI |
| Memory Density | 512 Mbit |
| Clock Frequency | 104 MHz |
| Operating Voltage | 2.7 V to 3.6 V |
| Source Catalog ID | C2641242 |
Selection Notes
The verified 2.7 V to 3.6 V operating range makes supply-domain compatibility a first screening check when comparing this part with lower-voltage Winbond family variants.
For exact-part selection, compare density, interface, clock ceiling and package together rather than matching only the base Winbond family.
Design Considerations
- Verify that the host I/O supply and logic thresholds are compatible with the 2.7 V to 3.6 V operating range.
- Use 104 MHz as the verified clock ceiling for first-pass controller configuration; apply the exact device timing requirements in the final design review.
Quality & Verification Support
Third-party inspection or testing can be arranged according to customer requirements. Testing fees are borne by the buyer. Additional verification requirements can be discussed before shipment. Physical product, label, packaging, and Date Code photos may be provided where appropriate.
Request a Quote
For W25M512JVEIQ quotation, provide the exact MPN, required quantity, destination, target Date Code if applicable, and any inspection or testing requirements.
