Key Selection Information
| Selection Parameter | Confirmed Information |
|---|---|
| Package | SOT-23-5 |
| Supply voltage | 1.65V~5.5V |
| Number of Channels | 1 |
| Operating Temperature | -40℃~+85℃ |
| Logic Family | 74LVC |
| Input Type | Schmitt trigger |
| Output Logic Level – Low | 550mV |
Product Overview
SN74LVC1G14DBVR is a Texas Instruments logic gate / inverter identified by the exact orderable code SN74LVC1G14DBVR. Its confirmed technical identity includes Supply voltage 1.65V~5.5V, Number of Channels 1, Operating Temperature -40℃~+85℃, Logic Family 74LVC.
The exact device is described as: Schmitt trigger 1.65V~5.5V [email protected],50pF 10uA 1 SOT-23-5 Gates and Inverters. Selection should be based on the exact package and the operating conditions required by the design, rather than on a nearby family member or a generic part number.
Technical Specifications
| Parameter | Value |
|---|---|
| Package | SOT-23-5 |
| Supply voltage | 1.65V~5.5V |
| Number of Channels | 1 |
| Operating Temperature | -40℃~+85℃ |
| Logic Family | 74LVC |
| Input Type | Schmitt trigger |
| Output Logic Level – Low | 550mV |
| Propagation Delay | [email protected],50pF |
| Features | Power shutdown protection;Noise suppression function |
| Input Logic Level – High | 1.16V~3.33V |
| Input Logic Level – Low | 390mV~1.87V |
| Output Logic Level – High | 2.3V |
| Quiescent Current(Iq) | 10uA |
| Current – Output High(IOH) | 32mA |
| Current – Output Low(IOL) | 32mA |
Selection Notes
- Package: SOT-23-5
- Supply voltage: 1.65V~5.5V
- Number of Channels: 1
- Operating Temperature: -40℃~+85℃
- Logic Family: 74LVC
Application Fit
This exact part is appropriate for designs that require a logic gate / inverter with the confirmed package and electrical/function parameters above. Final fit depends on the surrounding circuit, interface, thermal and mechanical requirements of the target design.
Design Considerations
Confirm the available supply rail stays inside the stated operating range, including startup and transient conditions.
Use the exact SOT-23-5 footprint/package definition when checking PCB land pattern, assembly clearance and sourcing equivalence.
Quality & Verification Support
Third-party inspection or testing can be arranged according to customer requirements. Testing fees are borne by the buyer. Additional verification requirements can be discussed before shipment. After an order is placed, physical product, label, packaging, and Date Code photos may be provided where appropriate.
Request a Quote
To request a quotation, provide the manufacturer part number, required quantity, destination, target Date Code if applicable, and any testing or inspection requirements.
