Key Selection Information
| Selection Parameter | Confirmed Information |
|---|---|
| Package | TQFP-100(12×12) |
| Supply voltage | 2.3V~3.6V |
| CPU Core | MIPS32 M4K |
| Maximum CPU speed | 40MHz |
| Program memory | 256KB |
| Operating Temperature | -40℃~+85℃ |
| Number of I/O | 81 |
Product Overview
PIC32MX550F256L-I/PT is a Microchip Technology microcontroller identified by the exact orderable code PIC32MX550F256L-I/PT. Its confirmed technical identity includes Supply voltage 2.3V~3.6V, CPU Core MIPS32 M4K, Maximum CPU speed 40MHz, Program memory 256KB.
The exact device is described as: MIPS32 M4K 32 Bit 40MHz TQFP-100(12×12) Microcontrollers. Selection should be based on the exact package and the operating conditions required by the design, rather than on a nearby family member or a generic part number.
Technical Specifications
| Parameter | Value |
|---|---|
| Package | TQFP-100(12×12) |
| Supply voltage | 2.3V~3.6V |
| CPU Core | MIPS32 M4K |
| Maximum CPU speed | 40MHz |
| Program memory | 256KB |
| Operating Temperature | -40℃~+85℃ |
| Number of I/O | 81 |
| ADC (Bit) | 10bit |
| Program Memory Type | FLASH |
| Core Size | 32 Bit |
| Oscillator Type | Built-in |
Exact-Part Selection Insight
The exact PIC32MX550F256L-I/PT orderable code ties 256KB program memory to the TQFP-100(12×12) implementation and 81 listed I/O. Moving to a nearby family member can change memory capacity or pin availability, so the firmware memory map and PCB pinout should be checked together rather than treating the family name as interchangeable.
Selection Notes
- Package: TQFP-100(12×12)
- Supply voltage: 2.3V~3.6V
- CPU Core: MIPS32 M4K
- Maximum CPU speed: 40MHz
- Program memory: 256KB
Application Fit
This exact part is appropriate for designs that require a microcontroller with the confirmed package and electrical/function parameters above. Final fit depends on the surrounding circuit, interface, thermal and mechanical requirements of the target design.
Design Considerations
Confirm the available supply rail stays inside the stated operating range, including startup and transient conditions.
Confirm memory size, available I/O, clocking and required peripheral set for the exact orderable device before freezing firmware and PCB pinout.
Use the exact TQFP-100(12×12) footprint/package definition when checking PCB land pattern, assembly clearance and sourcing equivalence.
